| Technical parameters of transverse belt break | Longitudinal tear parameter |
| 1. Lateral fault monitoring function: 24 hours x 365 days online real-time automatic monitoring | 1.Conveyor belt longitudinal tear identification accuracy: longitudinal tear length ≤20mm; Transverse crack width ≤1mm |
| 2. 0～8m/s（Detection speed: 0 ~ 8m/s | 2. Applicable bandwidth: 800-2400mm |
| 3. Joint positioning accuracy: 100% | 3. Processing speed: 80000*2048 pixels/second |
| 4. Measurement error of joint steel core tapping: ±2mm | 4. Image resolution: 1.0mm×1.0mm |
| 5. Qualitative accuracy of breaking core: > 99% | 5. Camera lateral field of view: 800-2800mm |
| 6. Quantitative error of broken core number: ±1 | 6. Monitoring speed: 1-8m/s |
| 7. Damage location accuracy: longitudinal length error: < 1‰; Horizontal coordinate length error: < 10mm | 7.Image recognition time: < 0.1s |
| 8. Joint identification accuracy: 100% | 8. Tear alarm response time: < 1s |
| 9. Major hidden danger real-time alarm braking stop response time: < 1s | 9.Damage location accuracy error: 0.1m |
| 10. Temperature: -20℃ ~ 60℃; Humidity: ≤95%RH | 10. Line frequency of line array camera: 80KHz |
| 11. Dustproof and waterproof rating: IP67 | 11. Normal service life of light source: > 30000h |
| 12. Historical data lookup function | 12. Environmental protection level: IP57 |
| 13. System remote debugging, diagnosis function | 13.Ambient temperature: -20℃~60℃; Temperature: ≤95%RH |
| 14.Safety certification: coal safety, explosion-proof certification | 14. Safety Certification Coal safety certification explosion-proof certification |
